Bosch 2608580312

Professional Summary

• Manufacturer: Bosch (Germany)

• Article / Part Number: 2608580312

• Tool Type: Diamond Dry Core Cutter (Dry Diamond Core Bit)

• Performance Class: High-grade diamond segment technology optimized for dry masonry drilling.

Dimensions & Specifications

• Diameter: 25 mm (the smallest diameter in this series, ideal for drilling tight, precise holes for thin pipes or individual electrical and fiber-optic cables).

• Working Length: 60 mm (effective drilling depth).

• Segment Count: 3 premium diamond segments attached via robust laser-welding.

• Mount / Thread Connection: M16 internal thread (requires a standard M16 adapter shank, such as SDS-plus or hex, and a centering pilot drill bit).

Key Features & Operating Guidelines

• Dry Operation: No water cooling required. Engineered with high thermal resistance to handle continuous dry cutting.

• Rotary Action Only (No Hammer): Must be used strictly in non-impact/rotary mode. Engaging the percussion or hammer setting will immediately break or shear off the diamond segments.

• Clean Performance: The compact diameter allows for rapid penetration and efficient dust extraction through the core slots.

Application Material Range: Perfect for cutting precise round holes in sand-lime brick, solid clay brick, aerated concrete (breeze blocks), masonry walls, and soft limestone.
