Mungo 5137105

Professional Summary

• Manufacturer: Mungo (Switzerland)

• Article / Part Number: 5137105

• Product Line / Type: m2r Throughbolt Anchor (Premium Wedge Anchor)

• Material Composition: Stainless Steel A4 (AISI 316). Provides exceptional, long-term corrosion resistance against moisture, salt water, industrial atmospheres, and chemical agents.

Dimensions & Installation Specs

• Thread Size ($d$): M10

• Total Anchor Length ($L$): 105 mm

• Drill Hole Diameter ($d_0$): 10 mm

• Maximum Fixture Thickness ($t_{fix}$): 30 mm (allows clamping of structural steel brackets, timber plates, or facades up to 30 mm thick).

Key Features & Engineering

• European Technical Assessment (ETA): Approved for high-performance structural anchoring in non-cracked concrete (Option 7).

• 3-Piece Expansion Clip: Features a specially engineered stainless steel expansion sleeve/clip that grips the concrete borehole evenly, ensuring highly secure load distribution and minimal slippage under tension.

• Cold-Formed Steel: Manufactured using precision cold-forming technology, which significantly enhances the tensile strength and structural integrity of the steel core.

• Safety Drive Pin: The top of the thread includes a built-in protection section to prevent damage to the threads when driving the anchor into the concrete with a hammer.

Application Range:

Engineered for heavy-duty structural anchoring in concrete $\ge$ C20/25 and dense natural stone. Widely used for securing exterior ventilated facades, structural steel beams, stadium seating, industrial machinery, glass balustrades, and outdoor metal railings.
